Nuestro sistema


temp-9

Sistema de retorno efectiva

Svenska Retursystem desarrollo y operación de sistemas de reciclaje de efectivo que simplifican y mejoran la logística de nuestros clientes y de la cadena de suministro.



Un sistema con muchas ventajas


Gracias a la estructura de las cajas los productos van mejor protegidos.

Las mismas unidades retornables en todas las cadenas de venta al por menor, independientemente de los productos.

El sistema está adaptado para la automatización y mejora el entorno de trabajo.

El respeto por el medio ambiente es una parte esencial de las actividades empresariales cotidianas.

Nuestros productos


Full-size 167 Black

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 600x400x194 mm
Working height: 167 mm under bale arms
Minimum inner bottom size: 546,5×349,5 mm
Loading capacity/crate: 20 kg
Stack capacity: 250 kg
Weight: 1.630 kg (+/- 2 %)
Empty crates/pallet, at delivery: 84
Pile of filled crates: First crate builds 194
mm, following crates 181,2 mm. Piles 6 crates high within total height off 125 cm including EUR/Paletten Pallets.

Full-size 110/140 Green

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 600x400x167 mm
Working height: 140 mm under bale arms
Working height: 110 mm under bale arms
Loading capacity/crate: Higher position 12 kg lower position 9 kg
Stack capacity: 162 kg
Weight: 1,530 kg +- 2 %
Empty crates/pallet, at delivery: 96
Pile of filled crates: First crate builds 167 mm, following crates 154 mm with the higher position of bale arm, 124 mm with the lower position of bale arm. Piles 7 crates high with the higher position within total height off 125 cm including EUR/Paletten Pallets, 8 crates high with the lower position of bale arm.

Full-size 50/80 Red

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 600x400x106 mm
Minimum inner bottom size: 552×352 mm
Working height: 80 mm under bale arms = 16 liter
Working height: 50 mm under bale arms = 10 liter
Loading capacity/crate: Higher position 7 kg
lower position 5 kg
Stack capacity: 158 kg
Weight: 1.208 kg (+/- 2 %)
Empty crates/pallet, at delivery: 104
Pile of filled crates: First crate builds 106 mm, following crates 93 mm with the higher position of bale arm, 63 mm with the lower position of bale arm. Piles 11 crates high with the higher position within total height off 125 cm including EUR/Paletten Pallets, 16 crates high with the lower position of bale arm.

Half-size 165 Black

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 400x300x193 mm
Minimum inner bottom size: 362X259 mm
Working height: 165 mm under bale arms
Loading capacity/crate: 11 kg
Stack capacity: 136 kg
Weight: 0,860 kg (+/- 3 %)
Empty crates/pallet, at delivery: 168
Pile of filled crates: First crate builds 193 mm, following crates 181 mm. Piles 6 crates high within total height off 125 cm including EUR/Paletten Pallets

Half-size 120 Red

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 400x300x148 mm
Minimum inner size: 362×257,5 mm
Working height: 120 mm under bale arms
Loading capacity/crate: 8 kg
Stack capacity: 136 kg
Weight: 0,764 kg (+/- 3 %)
Empty crates/pallet, at delivery: 176
Pile of filled crates: First crate builds 148 mm, following crates 136 mm. Piles 8 crates high within total height off 125 cm including EUR/Paletten Pallets

Half-size 50/80 Blue

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Size: 400x300x108 mm
Minimum inner bottom size: 357,8×253 mm
Working height: 50 mm under bale arms
Working height: 80 mm under bale arms
Loading capacity/crate: Higher position
5,5 kg lower position 2,5 kg
Stack capacity: 134 kg
Weight: 0,710 kg (+/- 3 %)
Empty crates/pallet, at delivery: 184
Pile of filled crates: First crate builds 108 mm, following crates 96 mm with the higher position of bale arm, 66 mm with the lower position of bale arm. Piles 11 crates high with the higher position within total height off 125 cm including EUR/Paletten Pallets, 16 crates high with the lower position of bale arm.

Half-size Pallet Black

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Colour: Black
Material: Polythene
Size: 800 x 600 mm
Height: 150 mm
Weight: 11,2 kg
Loading capacity: 500 kg
Estimated useful life: 15 years
Pallets per package, at delivery: 16
RFID: 13,56 MHz

Full-size Pallet Grey

Quieres saber más? Descargue nuestra hoja de producto para cajas (pdf).

Colour: Grey
Material: Polythene
Size: 1200 x 800 mm
Height: 150 mm
Weight: 14,8 kg
Loading capacity: 1000 kg
Estimated useful life: 15 years
Pallets per package, at delivery: 17
Environment: Reusable material
Temperature interval: -35°C – 40°C
RFID: UHF GEN2
Certification code GS1: 7350000486315
